Postby rendr » Fri Nov 21, 2008 12:50 pm

Wobble Guide
Wobble Bass

'Wobble Bass' as it is known is simply a bassline that has an LFO assigned to a Low Pass Filter as an insert effect. LFO stands for 'Low Frequency Oscillator' and is used to change a sound by a defined speed (measured in either Hz or synced to the Tempo in relation to the bars/notes through quantization.)
The way the LFO changes the sound is up to you, you can make the LFO adjust the Volume, the amount of Saturation, Filter Cutoff etc.
Basically any parameter you link it to. Essentially you are just using the LFO to send a changing value to a parameter.


--------------------


How to get a simple wobble bass.

1) Choose a simple sound on your synth. (Anything apart from a Sine wave )

2) Select your LFO and set it to the speed you want (1/8 would be a good starting point)

3) Now assign the LFO to the Filter Cutoff. Which should for this example be a Low Pass Filter* as the sound we're going for is a deep bass.

4) You now have a basic wobble bass, from here the possibilities for tweaking this sound are endless.


--------------------


A quick breakdown of what's actually going on. Essentially you are taking a sound (that can be an audio files, generated by a synth, etc) and then passing it through a Low Pass Filter.
Now what exactly does a Low Pass Filter do you ask?

* A Low Pass Filter allows Low Frequency signals to pass through it, but reduces the amplitude (volume) of all the Frequencies above the cutoff point. In general most plug-ins have various Low Pass Filter settings, where the more poles it has the more Dbs it will cut and will yield a harder knee to it. Example: 1 Pole Filter with a -6dB/Oct reduction Vs a 2 Pole Filter reducing -12Db/Oct.
However, you don't necessarily need a LFO controlling your Low Pass Filter Cutoff frequency value, you could just draw in the Automation yourself, but a LFO will yield a loop of consistent values and prevents the possibility of human error. All the LFO is doing is sending a value to your frequency cutoff to keep it consistently changing.


--------------------



Tips & Advice


1.) Sub bass wobble would normally be a Sine wave at around the 40-50 Hz range which would repeat the same chords as the mid-range bass wobble. The only difference being that with a sub bass wobble there is no point in assigning the LFO to a Low Pass Filter because the sound is too low for the low pass filter to have any effect, so the LFO is assigned to the amplitude (volume) instead. Another reason for not applying a Low Pass Filter to the Sub bass is because it would typically be a Sine wave which possesses no Harmonics to be adjusted by the Filter.

2.) The sound of an LFO can also be adjusted by the wave type you choose. The default setting for an LFO generator is a Sine wave, although on most synths you can chose from Triangle, Sawtooth, Square wave, Random, Noise. To get a nice sounding bass, it is a good idea to use as many oscillators as possible on different octaves.

3.) Try messing around with the attack and release of your sound as this can have an impact on the sound of the bass. Long attacks tend to create a more ambient sound, and is a technique traditionally used with ambient pads.

4.) Something that I find useful is to bounce the bassline to a .wav file, so that it can be chopped up and put in-sync with other elements of the song; because the majority of the time you will find the first wave of sound in the wobble bassline will will be half the length of the other waves due to attack rates. So the best thing to do is to chop that freak sound off the beginning of the file in your DAW (Logic Pro, Reason, Cubase etc) and start off with the second wave which should be fully formed. This way it will not be too early of late when keeping in sync with other elements such as a second bassline.

5.) Another method you can use is creating a clone layer of your original sound and setting up a new LFO setup for that to beat alternatively in the space left by the original LFO. Or go that crazy Drum & Bass Reese route and split the frequencies to Low, Mid and High, then set different LFO rates for each band then recombine into one sound.

6.) For more variation automate your LFO speed and intensity.

7.) Where you place insert effects in relation to the filter (pre or post) will yield different sounding results.

8.)
Other methods to achieve a wobble like sound:
Tremolo, (This effects volume rather than frequency)
FM Synthesis,
Modulation of PWM,
Oscillator Pitch assigned (in a liberal amount) to LFO.
Filter Envelope assigned to LFO (using a re-triggered envelope).
(submitted by Faun2500)

9.) Assign a second LFO to modulate the speed of the first LFO.




LFO Shapes

Sine wave: The smooth value change possible.

Triangle: Similar to a Sine wave but slightly more ramped & synthetic sounding.

Random: A mixed bag.

Sawtooth: Will have a very fast attack with a slower release which will sound very rugged.

Square wave: Will be a simple open close style. Very harsh and will generally cause a very harsh sound. (Often used in DJ Hazard style bass-lines). Detune two square waves for a nice dark sounding bass.









LINKS etc

Fruity Loops Wobble Tutorial (Link submitted by Wub)
Massive Wobble YouTube Tutorial (Video created by thesynthesist)
Pause & Play Wobble Tutorial (Link submitted by dubmo)
Albino3 Wobble Guide (Guide created by axon)





By Rendr & Deadly Habit ...and a little help from Macc.
Last edited by rendr on Tue Feb 10, 2009 5:44 pm, edited 23 times in total.
User avatar
rendr

Posts:
607
Joined:
Thu Nov 20, 2008 3:53 am
Location:
London
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby DZA » Fri Nov 21, 2008 12:56 pm

soooo whats a wobble ?
8)


Nice tutorial lads :wink:
jackmaster wrote:you went in with this mix.
.onelove. wrote:There needs to be a DZA app on iPhone just for id'ing old Grime tracks.

http://soundcloud.com/slevarance/metske-eprom-fail-slevarance
http://soundcloud.com/keepitgully http://www.mixcloud.com/slevarance/ http://www.facebook.com/profile.php?id=100002327637005
User avatar
DZA

Posts:
14608
Joined:
Tue Sep 18, 2007 11:43 pm
Location:
Notts
Has Bigged up!:
0 time
Been Bigged up!:
3 times

Postby deadly habit » Fri Nov 21, 2008 12:59 pm

step 9 is lfo shapes btw :wink:
deadly habit

Posts:
22594
Joined:
Tue Oct 24, 2006 4:41 am
Location:
MURRICA
Has Bigged up!:
7 times
Been Bigged up!:
36 times

Postby rendr » Fri Nov 21, 2008 1:06 pm

Deadly Habit wrote:step 9 is lfo shapes btw :wink:

Done :D
User avatar
rendr

Posts:
607
Joined:
Thu Nov 20, 2008 3:53 am
Location:
London
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby FSTZ1 » Fri Nov 21, 2008 3:35 pm

ham-r-time???

naww I'm just kiddin'
FSTZ1

Posts:
3438
Joined:
Thu Jun 12, 2008 4:27 pm
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby chewie » Fri Nov 21, 2008 4:30 pm

i reckon it sounds better if you use something with a bit of harmonics to get the sub bass wobble like a triangle with LFO to cut off rather than amp on the sine but really tend to use a square wave cos i like that wompy hollow sound you get with it. But anyway i was thinking of maybe putting up a few tutorials on how to get some fecked wobbles in massive using Sample and hold/pitch shifting and feedback loops with combs if anyone's down?
User avatar
chewie

Posts:
974
Joined:
Fri Jun 06, 2008 6:41 am
Location:
Melbourne, Australia
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby deadly habit » Fri Nov 21, 2008 4:33 pm

Chewie wrote:i reckon it sounds better if you use something with a bit of harmonics to get the sub bass wobble like a triangle with LFO to cut off rather than amp on the sine but really tend to use a square wave cos i like that wompy hollow sound you get with it. But anyway i was thinking of maybe putting up a few tutorials on how to get some fecked wobbles in massive using Sample and hold/pitch shifting and feedback loops with combs if anyone's down?

yea this was just meant to be a basic 101, but i could help you S&H and tracking generator based modulation and different filters (comb vowel etc) yield a lot of interesting results 8)
deadly habit

Posts:
22594
Joined:
Tue Oct 24, 2006 4:41 am
Location:
MURRICA
Has Bigged up!:
7 times
Been Bigged up!:
36 times

Postby macc » Fri Nov 21, 2008 4:39 pm

PMs DH
www.scmastering.com / email: macc at subvertmastering dot com
macc

Posts:
1737
Joined:
Thu Aug 28, 2008 12:56 am
Location:
http://www.scmastering.com , maac at subvertmastering dot com
Has Bigged up!:
0 time
Been Bigged up!:
5 times

Postby deadly habit » Fri Nov 21, 2008 4:40 pm

Macc wrote:PMs DH

is my box full?
deadly habit

Posts:
22594
Joined:
Tue Oct 24, 2006 4:41 am
Location:
MURRICA
Has Bigged up!:
7 times
Been Bigged up!:
36 times

Postby macc » Fri Nov 21, 2008 4:58 pm

Nope - I had to write the fucker :lol:
www.scmastering.com / email: macc at subvertmastering dot com
macc

Posts:
1737
Joined:
Thu Aug 28, 2008 12:56 am
Location:
http://www.scmastering.com , maac at subvertmastering dot com
Has Bigged up!:
0 time
Been Bigged up!:
5 times

Postby rendr » Mon Dec 01, 2008 12:34 pm

Still waiting for a reply from the mods on the sticky. :?
User avatar
rendr

Posts:
607
Joined:
Thu Nov 20, 2008 3:53 am
Location:
London
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby legend4ry » Mon Dec 01, 2008 1:06 pm

Some pictures would be nice explaining the first few steps on popular synths, such as massive & 3xosc.

I can do a FM8 picture tutorial if you want.


Hehe note : don't reply till you've read the whole post.


To be honest though put a * next to low pass filter just so people know it'l be explained.

Nice job though guys.
Soulstep wrote: My point is i just wanna hear more vibes


https://soundcloud.com/legend4ry/passover
User avatar
legend4ry

Posts:
10138
Joined:
Sun Oct 08, 2006 4:56 am
Location:
Plumstead SE18, London
Has Bigged up!:
5 times
Been Bigged up!:
21 times

Postby wub » Mon Dec 01, 2008 1:17 pm

I've found this tutorial;

http://audiotuts.com/production/how-to- ... -studio-8/

Works like a fucking dream as an intro to Wobble action in FL
JFK wrote:Wub is the DSF comedy master.


It's not who I am underneath, but my actions that define me


http://soundcloud.com/worldwidewub

AIM - wub2028
User avatar
wub
Global moderator

Posts:
31705
Joined:
Tue Feb 26, 2008 4:11 pm
Location:
Madrid
Has Bigged up!:
0 time
Been Bigged up!:
529 times

Postby rendr » Mon Dec 01, 2008 1:59 pm

Any other links you guys wanna post, I'll link 'em up. Thanks.
User avatar
rendr

Posts:
607
Joined:
Thu Nov 20, 2008 3:53 am
Location:
London
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby deadly habit » Mon Dec 01, 2008 3:06 pm

Legendary wrote:Some pictures would be nice explaining the first few steps on popular synths, such as massive & 3xosc.

I can do a FM8 picture tutorial if you want.


Hehe note : don't reply till you've read the whole post.


To be honest though put a * next to low pass filter just so people know it'l be explained.

Nice job though guys.

well i have pics in my kontakt wobble tutorial and since most NI soft has the same style interface...
deadly habit

Posts:
22594
Joined:
Tue Oct 24, 2006 4:41 am
Location:
MURRICA
Has Bigged up!:
7 times
Been Bigged up!:
36 times

Postby faun2500 » Tue Dec 02, 2008 9:58 am

LFO - tremelo
LFO - osc pitch (amount set very low)
Filter Envelope - LFO (using a retriggered env)
FM Synthisis (this can make woobles)
PWM (modulate it)

There are more creative ways to making a sound wobble. Its just about sitting down with a synth and having some fun fining out for yourself.


:)
User avatar
faun2500

Posts:
342
Joined:
Thu Oct 30, 2008 10:44 am
Location:
UK
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby deadly habit » Tue Dec 02, 2008 3:09 pm

yea there are but you have to admit this is the most asked about way for beginners
hell i could do an fm guide but trying to break down fm synthesis to a beginner... :o
and i wouldn't exactly qualify tremelo or pitch automation as what people here call wobble, but rather just simply tremelo and pitch automation :6:
deadly habit

Posts:
22594
Joined:
Tue Oct 24, 2006 4:41 am
Location:
MURRICA
Has Bigged up!:
7 times
Been Bigged up!:
36 times

Postby thesynthesist » Wed Dec 03, 2008 12:51 am

Thanks for the credit dude.... NOT
User avatar
thesynthesist

Posts:
500
Joined:
Sun Aug 12, 2007 9:05 pm
Location:
the Right side of Computo's brain...
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby rendr » Wed Dec 03, 2008 1:28 am

thesynthesist wrote:Thanks for the credit dude.... NOT

Sorry didn't notice you made the video; done now... and I love the subtlety. You sir, are the master of wit and humor!
User avatar
rendr

Posts:
607
Joined:
Thu Nov 20, 2008 3:53 am
Location:
London
Has Bigged up!:
0 time
Been Bigged up!:
0 time

Postby dubmo » Wed Dec 03, 2008 6:03 am

pause n play tutorial on wobble

http://www.youtube.com/watch?v=su7jbGQmBQc
dubmo

Posts:
4
Joined:
Sun Nov 23, 2008 9:19 pm
Has Bigged up!:
0 time
Been Bigged up!:
0 time
